    As people continue to improve comfort, economy and security requirements, the variety of electronic products on the car is increasing, and the failure rate of automotive wiring harnesses is increasing. Which requires improved wiring harness reliability and durability and other properties, many people for the automotive wiring harness process and production are more interested in here on the car harness process and production of this knowledge to be a simple description, you only need to spend a few Minutes to read, you can get a general understanding.
    After the two-dimensional product wiring out of the car harness, it is necessary to arrange the production process of the harness, the process is inseparable between the two services, so the author will combine the production and process of the car harness together.
    The first station of the wire harness production is the open process. The accuracy of the opening process is directly related to the entire production schedule, in the event of errors, especially the open line size is short, will lead to all the station rework, time and effort to affect production efficiency. Therefore, in the preparation of the opening process is sure to be based on the requirements of the drawings to determine the wire size, stripping head size.
    After the opening of the second station is the crimping process, according to the type of drawings required to determine the crimp parameters, the production of crimp operation instructions, for the special requirements of the need to indicate on the process file and training operators. For example: some wires need to wear through the jacket before crimping, it needs to first pre-installed wire and then returned from the pre-installed station and then crimping; there are punctured crimping with a dedicated crimping tool, which Kind of crimping method has good electrical contact performance.
    Then is the pre-installed process, and first to prepare the pre-installed process operating instructions, in order to improve the efficiency of the assembly, the complex wiring harness should be set pre-installed, pre-installed process is reasonable or not directly affect the efficiency of the assembly also reflects a Technical level of technical staff. If the pre-installed part of the assembly of less or assembly of the wire path unreasonable will increase the total assembly staff workload, slow down the speed of the assembly line, so the process staff should always be at the scene constantly summed up.
    The last step is the assembly process. Can be compiled according to the product development department design of the assembly board, design tooling equipment, material box size and all the assembly sheath and accessories number affixed to the material box to improve the efficiency of assembly. The preparation of the various parts of the assembly content and requirements, balance the entire assembly station to prevent the occurrence of a little workload is too large, pull down the entire assembly line speed situation. To achieve the balance of the station, the process staff must be familiar with each operation and on-site measurement of working hours, at any time to adjust the assembly process.
    In addition, the wiring harness process also includes the preparation of material consumption quota schedule, man-hour calculation, worker training, etc., because the technical content value is not high, these are not elaborate. All in all, the automotive wiring harness in the car electronic technology content and quality, has gradually become an important indicator of vehicle performance evaluation. Car manufacturers for the choice of wire harness should pay special attention to, it is necessary to understand the next car wiring harness process and production.
